Kompressor Bitzer Tipe 4J-13.2

Rp. CALL
Last Updated
21 Sep 2021
Minimum Order
1 unit

Specification of Kompressor Bitzer Tipe 4J-13.2


Technical Data


Si

Ip


Motor Version

2

2


Displacement ( 1450 Rpm 50Hz)

63.5 M3/ H

2242.5 Cfh


Displacement ( 1750 Rpm 60Hz)

76.64 M3/ H

2706.5 Cfh


No. Of Cylinder X Bore X Stroke

4 X 65 Mm X 55 Mm

4 X 2.56 Inch X 2.17 Inch


Motor Code

40P

2Nu


Motor Voltage ( More On Request)

380..420V Yy/ 3/ 50Hz

440..480V Yy/ 3/ 60Hz


Max Operating Current

27.0A ( Y)

26.5A ( Y)


Maximum Power Consumption

15.7 Kw

15.7 Kw


Winding Ratio

50% / 50%

50% / 50%


Starting Current ( Rotor Locked)

81.0A/ 132.0A ( Y/ Yy)

147.0A


Enclosure Class

 Ip54

 Ip66

 Ip54

 Ip66


Weight

179 Kg

395 Lb


Maximum Pressure ( Lp/ Hp)

19 / 28 Bar

275 / 400 Psi


Connection Suction Line

42 Mm

1 5/ 8"


Connection Discharge Line

28 Mm

1 1/ 8"


Oil Charge

4.00 Dm3

140.8 Fl Oz


Crankcase Heater

140 W

140 W


Oil Type R134a / / R407a/ C/ F / / R404a / / R507a

 Tc55° C: Bse55

 Tc130° F: Bse55


Oil Type R22 R22 ( R12 / / R502)

 B5.2

 B5.2


Oil Pressure Monitoring

 Mp54

 Delta P

 Mp54

 Delta P


Oil Service Valve


Oil And Gas Equalizing Fittings


Capacity Control

 100% / 50%

 100% / 50%


Start Unloading


Check Valve ( For Start Unloading)


Motor Protection

 Se-B2

 Se-B2


Bridges For Dol Start


Discharge Gas Temperature Sensor


Discharge Shut-Off Valve


Suction Shut-Off Valve


Additional Fan


Water-Cooled Cylinder Heads


Connection Cooling Water

R 3/ 4"

R 3/ 4"


Seawater Resistened Cylinder Heads


Kit For Marine Application


Cic System


Vibration Dampers


Sound Power Level ( -10° C / 45° C)

77.5 Db( A) @ 50Hz

80.0 Db( A) @ 60Hz


Sound Power Level ( -35° C / 40° C)

81.0 Db( A) @ 50Hz

83.5 Db( A) @ 60Hz


Sound Pressure Level @ 1M ( -10° C / 45° C)

69.5 Db( A) @ 50Hz

72.0 Db( A) @ 60Hz


Sound Pressure Level @ 1M ( -35° C / 40° C)

73.0 Db( A) @ 50Hz

75.5 Db( A) @ 60Hz


Lihat Selengkapnya

Untuk keterangan lebih lanjut, silahkan download PDF ini :
